3-Piece Can Making
High-speed Welder
;)
;)
As the core of 3 piece can production line, the welder we provide wins overwhelming favor from diverse manufacturers of beverage can, food can and aerosol can with the feature of high efficiency, stability and easy maintenance. This welder wins overwhelming favor from diver manufacturers of food, beverage and aerosol can with the feature of high efficiency, reliability and quick tooling change.
Technical Parameters:
Max. Welding Speed | 85m/min |
Max. Output Capacity | 800cpm (Depends on Can Height) |
Overlap | 0.3-0.4mm |
Can Diameter | Ф52- Ф153mm |
Can Height | 70-320mm |
Sheet Thickness | 0.16-0.3mm |
Welding Frequency | 200-1000HZ |
Total Power | 150kW |
Weight | 4000kg |
Overall Dimension | 4650 x 2300 x 2500mm |
Optional for Mercury Free System | |
